EasyPak EP500 by HydroQuip is the budget-priced, pump-top spa air control system designed for easy installation. Ultra-compact, non-metallic housing mounts directly to the hot tub pump.
You choose the right options for your spa, and the controller comes configured to your preferences. 120V systems come with 3-prong GFCI cord. Heater is pressure-switch & high-limit protected. Operates on timer or thermostat mode.
Standard Circuits: 120V Pump, Blower, Ozonator, Heater
Upgrades: Optional Light Kit
Included with your new EasyPak:
- Color-coded Accessory Cords
- Air Buttons & Tubing for Pump & Blower
- 1.5″ Union Fittings & Gaskets
- 15A Inline GFCI Power Cord
- Installation Guide
Product notes: GFCI cord must be served by a properly grounded outlet. Voltage selection is not convertible. User and Electrician’s Guides included. 2-year factory warranty. For 2″ plumbing, see BX9924 Reducer Unions below. Sorry, not shippable outside the contiguous-48 USA.
More information:
Details:
Pump Circuit: 2-Speed, 120V only (13A max) – With air button & tubing
Blower Circuit: 120V only (8A max) – With air button & tubing
Ozone Circuit: 120V only (2A max)
Timer: 24 Hour
Mode Switch: Timed Heat / Timed Filtration -OR- Thermostat Heat / Timed Filtration
Built-in Heater: 120V (1.25kW)
Heater Indicator: Heat On Light
Thermostat: Full Range
Overheat Protection: Built-in Manual reset button
Pressure Switch: Built-in
Power Cords: Provided for each circuit – 48″ & color-coded for easy identification
Light-ready Circuit: 120V Hot receptacle
Light Kit Upgrade: 120V> 12V – Complete installation kit with colored lenses
Case: Rust-free ABS
Replaces:CS500T-A, CS500T-C, CS500T-A-15A, HT500T, HT502T, VOAAB2A-11004EO, 3-70-0091, 3-70-0901A, 58-355-1030, 58-355-1050, & more.
